MFOS Sound Lab Mini-Synth in SMT – Assembly Instructions – v1.4

This is the build documentation for version 1.4. It’s an update from V1.3 documentation. The version 1.4 is the latest and final version. All previous corrections and mods have been integrated and thus it’s fully working and requires no further modification.

MFOS Sound Lab Mini-Synth is a cool analog monophonic synthesizer. The original version has been created by Ray Wilson from Music From Outer Space.

The Eurorack Sound Lab Mini-Synth

Continue reading MFOS Sound Lab Mini-Synth in SMT – Assembly Instructions – v1.4

MFOS Sound Lab Mini-Synth in SMT – Assembly Instructions – v1.3

This is the build documentation for version 1.3. It’s an update from V1.2 documentation. A newer version is also available. Please, check the latest information here.

MFOS Sound Lab Mini-Synth is a cool analog monophonic synthesizer. The original version has been created by Ray Wilson from Music From Outer Space.

The Eurorack Sound Lab Mini-Synth

Continue reading MFOS Sound Lab Mini-Synth in SMT – Assembly Instructions – v1.3

Eurorack Power Bus – Update 1.1


The Eurorack Power Bus with its 14 Euro connectors is back in an updated version.

The version 1.1 slightly simplifies the BOM and adds a second power input terminal, either for chaining to a second bus or to ease the installation as PSU cables can be wired either from the bottom or from the top of the case.

The Eurorack Power Bus board is a convenient way to distribute the required power voltages across a small-to-medium Eurorack system.

There are 14 Eurorack connectors so up to 14 modules can be powered at once. Two additional 16-pin DIL connectors are dedicated to Analogue Systems compatible modules. Plus, six 3-pin connectors are present for your powered 1U modules.

The bus can be equipped with a onboard +5V linear regulator.

The 3 LEDs let you know if the 3 power rail voltages are present. The form factor of the bus is 20cm long, 5cm wide. The short distance between the connectors ensures lower voltage drops under high current consumption.

Building the Eurorack Power Bus

The build process is simple:
Start by soldering the three resistors. The resistors are not polarized. R1 and R2 are 1k Ohms (Brown, Black, Red, Gold). R3 is 470 Ohms (Yellow, Violet, Brown, Gold).
See Resistor color code chart.

If you use the onboard +5V regulator, add now the two 1N4007 diodes. They are polarized. Follow the white band marking on both silkscreen and the diode case. The white band shows the Cathode side of the diodes.

Bend the leads of the +5V regulator U1 (7805) at 90°, according to the silkscreen.
You can either bolt the regulator to the PCB or solder the metallic tab to the square pad. Soldering the tab requires to apply enough heat to both the PCB and the regulator heat sink. The solder must flow under the metallic tab to effectively bond the regulator to the PCB.

+5V Regulator and its required components

If you intend to use Analogue Systems compatible modules, you can solder in place the two 16-pin DIL sockets. If not, you can simply skip this step.
The DIL socket is polarized: align the notch to the silkscreen marking.

If you intend to use the 1U connectors, you can nw solder the six 3-pin connectors. If not, you can simply skip this step. Those connectors may require some adjustment to be correctly aligned vertically. Try to solder one pin at a time and then adjust the position.

Eurorack Power Bus V1.1 – Top side
Eurorack Power Bus V1.1 – Bottom side

Interactive BOM (bus_eurorack-1.1-ibom-2019-01-17)

As usual, you can find the Eurorack Power Bus PCB on Tindie.
